Yotsuba Moto WOOF16

A new species has been born at YotsubaMoto. Its name is WOOF. A convertible 2-in-1 motorcycle: Motocross and Trial.

With a power output of 750/1500w, 48v voltage, aluminum frame, front and rear suspension, and disc brakes for a more authentic ride.

The motorcycle is designed to enjoy three different specialties with a single bike. By changing the mounting position on the swingarm, the dimensions of the motorcycle can be adjusted, allowing for a configuration for Motocross and/or Trial.

WARNING

The Yotsuba WOOF motorcycle cannot be ridden on public roads. It is recommended to ride and enjoy this bike in closed parks or private properties, always under the supervision of an adult.

FEATURES

CONVERTIBLE WOOF

The main feature of the WOOF is that it can be configured in dimensions as an Off-road or Trial bike by changing the swingarm mounting position and making the seat removable. It only takes about 5 minutes to change the size, making it easy to switch depending on the terrain.

10AH LITHIUM BATTERY

The battery has a capacity of 10Ah, which is enough for 2-3 hours of operation. Continuous running time is about 50 minutes in dry conditions and about 45 minutes in wet conditions. For Trial use, a single battery is usually enough for a full day of use. The battery can be quickly replaced with the sliding system for easy swapping. The estimated charging time is about 3 hours.

POWER ADJUSTMENT AND MODES

WOOF has a continuous dial-type power adjustment to adapt to the young rider's skill level. Additionally, the mode switch allows you to choose between the acceleration-oriented mode (sunny mode) and the traction-oriented mode (rainy mode). There is no change in top speed or hill-climbing capacity when using either mode.

GYROSCOPIC SENSOR

A gyroscopic sensor detects falls, activating and stopping the motor when the tilt exceeds 65 degrees.

ALUMINUM FRAME

The frame is not painted or treated with an oxide coating. The user can polish and enjoy the texture of the aluminum material as it changes over time, but regular polishing or waxing is required.

SUSPENSIONS AND DISC BRAKES

It is equipped with front and rear suspension and cable-pulled disc brakes. The standard brake levers are designed for smaller diameter handlebars.

HUB MOTOR

This motorcycle has no chain or sprockets. It uses a hub motor built into the rear wheel, reducing the possibility of getting fingers or feet caught in chains or sprockets. Its configuration (with the motor near the ground) provides a lower center of gravity and helps when picking up the bike. The power output is 48V 750W (nominal) / 1500W (peak). The maximum speed on flat terrain is 40 km/h.

TIRES

Like the Meow, it uses standard bicycle tires to reduce weight. The tire tread provides adequate grip for both on-road and off-road use. To ensure sufficient air volume, a larger size has been selected compared to bikes of the same size.

PROTECTOR

To protect the battery, the bike is equipped with a sturdy 3 mm thick lower guard. Its design has been conceived to withstand impacts when riding over rocks and logs.

WOOF 16 SPECIFICATIONS

• Length: 1365 mm (1320)
• Width: 600 mm
• Height: 790 mm (805)
• Wheelbase: 950 mm (905)
• Minimum seat height: 563 mm (485)
• Ground clearance: 170 mm (200)
• Steering angle: 26° (23°)
• Frame: AL6061
• Front fork: AL6061
• Front suspension: Telescopic
• Rear suspension: Mono shock
• Front brake: Disc
• Rear brake: Disc
• Wheel size: 16 x 2.4
• Weight: 25 kg
• Top speed Fast/Medium/Low: 40 km/h
• Motor: Hub motor
• Battery: Lithium 48 V / 10 Ah
• Power: 750 / 1500 W
• Voltage: 48 V
• Charging time: 3 hours
• Battery life Fast/Medium/Low: 30 / 60 / 100 minutes
• Maximum recommended weight: 55 kg
• Recommended age: 7 years and up
